300V mPPE Wire UL11027 22AWG Solid 1/0.643 OD1.15mm Black

Product Categories
WCH Cable Industrial Co., Ltd.
Contact Now

300V mPPE Wire UL11027 22AWG Solid 1/0.643 OD1.15mm Black

Brand Name : WCH Cable

Model Number : UL11027

Certification : UL, Cul, AWM, HF

Place of Origin : Dongguan, China

MOQ : 1220 meters

Price : USD0.0493 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 40,000,000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 610 meters per reel

UL Style : 11027

Gauge : 22AWG

Conductor Type : Solid

Conductor Material : Pure Copper Wire

Overall Diameter : 1.15mm

Colour : Black

Contact Now

300V mPPE Wire UL11027 22AWG Solid 1/0.643 OD1.15mm Black

Conductor Specification (AWG) 22
Section Area (mm²) 0.3247
Material 　 Tinned stranded copper
Configuration (mm) TS1/0.643±0.007
Insulation Ave Thickness (mm) 0.24
Min Thickness (mm) 0.19
Over Diameter (mm) 1.15±0.10
Material 　 MPPE (RoHS)
Colour 　 Black
Electrical
Capability		 Rated Temperature (℃) 105
Rated Voltage (V) 300
Conductor Resistance (Ω/KM 20℃) 56.40
Insulation Resistance (MΩ/KM 20℃) 100
Flammability Fire Retardance 　 VW-1
　 　 FT1
Approval UL Style Number 　 11027
CSA Grade 　 I A/B
Environmental Standard 　 Lead Free
　 　 RoHS & Reach Compliant
